Facility & Utility Requirements
Power: Controller: 220V - 2Phase, 60(50)Hz, 7.3A, 1.6KW
Electric Transformer
Input: 380V - 3Phase, 60(50)Hz, 33A, 16.5KW
Output: 220V - 3Phase, 60(50)Hz, 43.4A, 16.5KW
Gas Supply
Inlet Pressure: <600KPa;
Gas Tubes: Ø6.0mm;
Connection Hose Coupling (External): Ø6.0mm
Operative Environment:
Ambient Temperature: 5 – 40℃;
Relative Humidity Range: 50% (40℃) - 80% (31℃)
Process Control
Temperature Module(Heating Only – Electrical Heating Plates):
Temperature Control:RT - 70℃
Heating Capacity: 2 x 650W (220V)
Over Temperature Protection: Maximum 75℃ (Bi-metal Interrupted Heating)
Gassing Module Control Box:
MFC Flow Rates: 0.4 - 20 LPM
MFC Accuracy: ±1.0% F.S. (25℃)
4-Gas Mix (O2, N2, CO2, Air) With Headspace Outlet
DO Cascade: Available
Sensor & Measurement
Temperature Probe Pt 100:Temperature Range: 0 - 150℃;
Display Resolution: 0.1℃;
Amplifiers: 1
pH Single Use: pH Range: 6 – 10pH
Display Resolution: 0.01pH
Amplifiers: Maximum 2
Recalibration Function: Available
DO Single Use: Saturation Range: 0 – 250%
Display Resolution: 0.1%
Amplifiers: Maximum 2
Recalibration Function: Available
Load Cells: Load Cells: Optional; Weight Range Accuracy: 250g per 100kg
Balance Substrate: Optional: Up to 4 per Side
External Signal Input: 4 (0 – 5V DC)
Pump Module
Internal Pumps: 3 (WM313)
Control Range (Fixed Speed): 19 – 190 rpm
Communication & Technical Data
Communication: Industrial Ethernet: Optional
Technical Data
Maximum Total Volume (L): 625
Working Volume (L): 125-300 (20 – 48%)
Rocking Rate (R/Min): 14 – 32 ± 1
Rocking Angle (º): 6 – 12 ± 0.5
Free Orbital Rocking Rate (R/Min): 14 – 32 ± 1
Free Orbital Rocking Angle (º): 6 – 12 ± 0.5
Sensor Clamps for Secure Fixation of Glass Fiber Cables: 2
Filter Heater: Available
Color Touch Screen: Available
Safety Measurement & Shut-Off: 30mbar
Measurement Data Storage: Optional SD Memory Card
