Frequency:20Hz-500KHz
Turn Ratio Frequency:50Hz ~ 200kHz (10Vac Max.)
Measurement Parameters:
Inductance (L)、Impedance (Z)、Capacitance (C)、Resistance (R)、
Conductance (G)、Susceptance (B)、Admittance (Y)、Alternating Current Resistance (ACR)、
Quality Factor (Q)、Phase angle(Ø)、Direct Current Resistance (DCR)、Leakage Inductance,
Turn Ratio、Balance、Short Circuit
Basic Accuracy:±0.1% (AC parameter : 1KHz)
Output Impedance:100Ω
Frequency trimming resolution:5digits
Frequency output accuracy:±0.01%
Point of Test:20 Points
ESR :Series/Parallel
Mathematical Mode:Absolute/Percentage
Calibration:Open Circuit/ Short Circuit
Power Supply:Voltage 98Vac~132Vac or 195Vac~264Vac/47Hz~63Hz
Frequency 48Hz ~ 62Hz
Display: 800*480 7" TFT LCD
Interface:RS-232, LAN, Handler, USB Host
Flash Memory:128 sets
Operation: Auto, Manual,Remote Trigger
Environment:Temperature : 10℃ ~ 40°C Humidity : 10 ~ 90%
Dimension (W*H*D):344x145x343mm
Weight:3Kg
