Test Frequency:10Hz-1MHz
Points Of Test Frequency: Continuity
Basic Accuracy: ± 0.08%
AC Drive Level: 10mV to 2Vrms (1m Vrms solution)
DC Drive Level: 0.01V-2V
Output Impedance: 100Ω
Frequency trimming resolution: 5 Digits
Frequency output accuracy: ±0.01%
AC / DC test speed Max.: 8mS
Measured Value Detection Mode:Define upper and lower thresholds according to main and sub parameters
ESR:Series/Parallel
Mathematical Mode:Absolute/Percentage
Test Range:Automatic/Lock
Indicator:Pass/Fail and Built-in speaker
Safety:EN61010-1
Immunity:EN61326-1
Emissions:EN55022 Class A
Calibration:Open Circuit / Short Circuit: Avoid the misreading caused by the stray capacitance from kelvin clips and fixtures
Auto-save when power-off function: When the power is turned off or encounter a power outage, all the data will be saved automatically and recovered when tester system is switched on again
Power Supply:Voltage 90-132Vac or 198-264Vac (selectable)
: Frequency 47 ~ 63Hz
Display:320*240 dot-matrix display
Interface:RS-232, GPIB(option), Handler(option)
Flash Memory;Built-in SDRAM for storage of 64 groups of Multi-steps setting (Each group contains up to 30 steps)
Operation:Auto、Manual、RS-232、GPIB(option)、Handler(option)
Temperature : 10°C to 40°C Humidity : 20 ~ 90%
Dimension (W*H*D):337x145x522 mm
Weight:6.5 Kg
