Working disc diameter: φ250mm（customized φ230，φ300mm）
Working disc speed (rpm): 50-1000 r/min（Variable speed), 300 / 600 / 900 r/min（three fixed speed）
Rotation direction: Clockwise and counter clockwise
Speed of grinding and polishing head: 5-150 r/min（variable speed）
Preparation sample quantity: 6pcs
Force loading Range: Individual 20-70N, central 150-300N
Sample preparation time: 0-3000 S
Specimen diameter: Standard φ30mm（customized φ22-φ45mm）
Input voltage: Single phase 220V±10%，50-60Hz
Total power: 1100W
Overall dimension: 750*550*670mm
Net weight: 62kg
Standard Delivery
Machine Mainframe: 1 set
Polishing Cloth Φ250mm: 2 pcs
Abrasive Paper Φ250mm: 4 pcs
Grinding Disc Φ250mm: 1 pc
Aluminum Retaining Ring Φ250mm: 1 pc
Outlet Pipe: 1 pc
Inlet Pipe: 1 pc
Pressure-Resistant Hose Φ8*3000mm: 1 pc
Oil-Water Separator: 1 pc
Magnetic Disc: 1 pc
Anti-Adhesion Disc: 13 pcs
Leveling Feet: 4 pcs
Power Cable: 1 pc
Anti-dust Cover: 1 pc
Water Shield: 1 pc
Central Sample Holder: 1 pc
Single Sample Holder: 1 pc
Plastic Cover: 1 pc
Central Clamping Dev
Optional Delivery
Silicon Carbide Abrasive Paper: SC-A
Aluminum Oxide Abrasive Paper: AO-WA
Polishing Cloth: VC/WC/SC/CC/NC/FC/SPC-A
Monomorph Diamond Suspension: DSM
Polycrystal Diamond Suspension: DSP
Aluminum Oxide Suspension: AOS
Silicon Suspension: SOP
