Disc Diameter: 230mm
Abrasive Paper Diameter: 230mm
Disc Speed: Stepless Speed 100~1000r/min, or Four Speeds 250, 500, 750, 1000r/min
Disc Rotational Direction: Clockwise or Counterclockwise
Disc Electromotor: DC Brushless Motor, 220V, 600W
Head Electromotor: Stepper Motor, 200W
Head Speed: Stepless Speed 20~120r/min
Timing Set: 0~99min
Sample Holding Qty.: 4 pcs
Sample Holder Specification: Φ25mm, Φ30mm, Φ40mm (Choose One) or Customized Specification
Pressure Method: Single Air Pressure
Pressure Force: 0~60N
Control and Display: Keypanel Operation , LED display, Grinding Head Automatic Locking and Washing Function
Power Supply: 220V, 50Hz, 6A
Machine Dimensions: 420×660×630mm
Net Weight: 50kg
Packing List
Machine Mainframe: 1 set
Grinding Head: 1 pc
Grinding Polishing Disc: 230mm: 1 pc
Magnetic Disc: 230mm: 1 pc
Teflon Pad: 230mm: 4 pcs
Abrasive Paper: 230mm: 6 pcs
Polishing Cloth: 230mm: 2 pcs
Water Inlet Pipe: 1 pc
Water Outlet Pipe: Φ32mm: 1 pc
Water Inlet Filter: 1 pc
Air Pipe: Φ6mm: 1 pc
Air Filter: 1 pc
Inner Hexagon Spanner: 2mm, 3mm, 5mm: each 1 pc
Usage Instruction Manual: 1 copy
