Platen Diameter: 250mm
Abrasive Paper Diameter: 250mm
Platen Disc Type: Magnetic
Platen Disc Speed: Stepless 100~1000r/min
Platen Disc Direction: Clockwise or Counter-Clockwise
Platen Disc Motor: DC brushless motor, 220V, 1.2kW
Head Motor: 200W Stepper Motor
Head Lock: Automatic
Water Outlet: Automatic
Head Disc Speed: Stepless 20~120r/min
Timing set: 0~99min
Program Storage: 10 Saved Steps
Sample Holder Qty.: 6 pcs
Sample Holder: Standard: Φ25mm, Φ30mm, Φ40mm (Choose one) Customized different sizes and shapes
Pressure Method: Single Pressure or Central Pressure
Single Sample Force: 0~50N
Central Sample Force: 0~160N
Control Panel: 7 inch Touch Screen
Power Supply: 220V, 50Hz, 12A
Machine Dimensions: 1200×800×760mm
Net Weight: 134kg
Standard Single Force Sample Holders
Φ25mm(Standard): 6pcs: Plastic Retaining Rings
Φ30mm(Standard): 6pcs: Plastic Retaining Rings
Φ40mm(Standard): 6pcs: Plastic Retaining Rings
Standard Central Force Sample Holders
Φ25mm(Standard): 6pcs: Plastic Retaining Rings
Φ30mm(Standard): 6pcs: Plastic Retaining Rings
Φ40mm(Standard): 6pcs: Plastic Retaining Rings
Standard Delivery
Machine Mainframe: 1 set
Grinding Head: 1 pc
Single Force Sample Holder: 1 pc
Sample Leveling Plate: 1 pc
Grinding and Polishing Disc: 1 pc
Magnetic Disc: 1 pc
Teflon Pad: 4 pcs
Abrasive Paper: 6 pcs
Polishing Cloth: 2 pcs
Water Inlet Pipe: 1 pc
Water Outlet Pipe: 1 pc
Water Inlet Filter: 1 pc
Air Pipe: 1 pc
Head Connection Cable: 2 pcs
Inner Hexagon Spanner: each 1 pc
Instruction Manual: 1 copy
