MKS 740D General Purpose Gauge Baratron® Capacitance Manometers (20 Torr to 3000 psig)

Specifications

Media: Gas, Liquid

Pressure Ranges: 20 Torr to 3000 psig (1.4 to 204 bar)

Accuracy (includes non-linearity, hysteresis and non-repeatability): ±1% Reading, 0.1% Full Scale

Repeatability: ±0.1% of Reading

Resolution (output): 0.01% of Full Scale

Ambient Operating Temperature: 0° to 50°C

Temperature Effect:

Zero: 0.02% of Full Scale/°C

Span: 0.04% of Reading/°C

Response Time: <20 msec

Excitation:

0-5 VDC output: 13 to 32 VDC @ 10 mA max

0-10 VDC output: 13 to 32 VDC @ 10 mA max.

4-20 mA output: 13 to 32 VDCmA

Electrical Termination:

9-pin D-subminiature

Bendix PTO 4-Pin

6 ft (2m) flying lead

Overload-Safe: 45 psig or 2× Full Scale, whichever is greater

Overload-Burst:

up to 1000 psi: 100 psia or 10× Full Scale whichever is greater

>1000 psi: 5× Full Scale

Internal Volume: Single-ended 0.3 cu. in.

Wetted Parts Material: Inconel and 316L S.S.

Weight: Single-ended 0.5 lbs (0.2 kg)

Compliance: CE

For specific range please check the attachment below!
