Full Scale Flow Range: 100-250 slm (N2 equivalent)
Fitting Type: 12 mm Swagelok; 0.375 in. Swagelok; 0.5 in. tube compression; 0.5 in. compression long; 0.5 in. NPT female; 8 VCR male; 8 VCO male; 8 VCR male long; 8 VCO male long; W-Seal
Connector: Profibus (1179B Compatible); Profibus (1480 Compatible); PROFINET; 15 pin D (Analog 0-5 VDC I/O); 15 pin D (4-20 mA I/O)
Maximum Inlet Pressure: 150 psig
Normal Operating Pressure Differential: 30-55 psid
Burst Pressure: 1500 psig
Control Range: 2-100% of Full Scale
Typical Accuracy: ±1% of set point for >20% to 100% Full Scale
±0.25% of Full Scale for 5% to 20% Full Scale
Repeatability: ±0.5% of Reading
Resolution: 0.1% of Reading
Zero Temperature Coefficient: <0.05% of Full Scale/°C
Span Temperature Coefficient: <0.08% of Rdg./°C
Inlet Pressure Coefficient: <0.03% of Reading
Typical Settling Time: 1 to 2 seconds typical above 10% Full Scale @ 50 psi
Warm-up Time: 1 hour
Operating Temperature: 10-50°C
Storage Humidity: 0 to 95% Relative Humidity, non-condensing
Storage Temperature: -20° to 65°C
Enclosure Rating: IP66
Power Requirements: +15 to +24 VDC @ (<4 watts)
Flow Input Output Signal: Voltage: 0 to 5 VDC. Current: 4 to 20 mA
Weight: 4.5 lbs. (2.05 kg)
Compliance: CE
For specific range please check the attachment below!
