Drilling cap. - steel / cast iron: 38 / 50 mm
Tapping cap. - steel / cast iron: M25/ M32
Boring cap. - steel / cast iron: 75 / 105 mm
Spindle stroke: 200 mm
Horizontal travel of headstock: 500 mm
Column diameter: Ø210 mm
Base size: 1280 x 640 x 150 mm
Table size: 550 x 405 x 315 mm
Spindle center to column surface: min. 290 mm/max. 765 mm
Spindle nose to base: min. 282 mm/max 1110 mm
Spindle speed: 88 ~ 1500 rpm , (6 steps)
Spindle taper: MT#4
Spindle motor: 2 HP
Net weight: 1100 kgs
