Test Specifications:
Diagnostic Modes: IR, PI, DAR, DD, SV, BDV, Burn
Test Voltage:
Programmable Test Voltage: 250V, 500V, 1000V, 2500V, 5000V, 7500V, 10000V
Lock Test Voltage: 250 - 1000V adjustable in steps of 10V, 1000 - 10000V adjustable in steps of 25V
Voltage Accuracy : ± (5% of reading + 5 digits)
Resistance Range :
Analog Display: 10KΩ - 10TΩ
Digital Display: 10KΩ - 50TΩ
Accuracy: 1 MΩ to 1 TΩ ± (5% of reading + 5 digits); 1 TΩ to 10 TΩ ± (10% of reading + 5 digits); 10 TΩ to 50 TΩ ± (20% of reading + 7 digits)
Guard Resistance: 2% error guarding <300KΩ
Short Circuit/Charge Current:
Short Circuit current: up to 6mA
Current Range: up to 6mA
Accuracy at 25°C at 10 KV: 6mA ± 0.7mA
AC/DC Voltage:
Voltmeter Range: 0 ~ 600 AC/DC
Voltmeter Accuracy: ±(8% of reading + 5 digits), input resistance: 250MΩ Approx
Capacitance Measurement:
Capacitor Discharge Time: ≤ 5 sec per μF
Capacitance Range: 1nF to 50μF
Capacitance Measurement Accuracy: ± (5% of readings + 5 nF)
Interference Rejection : 1mA RMS per 250V test voltage up to a max. of 4mA
Timer : Programmable timer from 0 sec to 99 minutes
Memory: Internal data storage of 1000 readings
Interface : Galvanically isolated RS232 and USB ports; remote operation via PC using either RS232 or USB cable
Data Handling & Analysis Software : Operated on XP/Windows7/Windows8/Windows10/Windows11; Two way communication for remote operation; Report generation along with the graphical representation for Data Trending Analysis.
Power Supply:
Mains Input Voltage: 85V/265V RMS, Frequency 50/60Hz ±10%
Battery Type: Battery Pack, Rechargeable 14.8V, 5200mAh, Li-Ion, Type 18650
Battery Life: 8 hours continuous testing at 10kV with a 250 MΩ load (approx)
Battery Charge Time: 8 hours approx. (95% Charged)
Auto Power Off: Instrument turns off after 10 minutes of non-use to conserve battery life
Environmental Condition:
Operating Temperature Range: -10°C to 55°C
Storage Temperature Range: -20°C to + 70°C.
Humidity: < 95% RH Non-Condensing
Safety :
Safety in accordance with EN61010-1
EMC in accordance with EN61326-1
Type test in accordance with IEC 60068
Test lead in accordance with IEC 61010-31
CE & CAT III 1000V & IV 600V, IP 65
Physical Specifications:
Dimensions: 190 mm X 285 mm X 365 mm (Approx.) (H x W x L)
Weight: 5 Kg (approx) (without accessories); 9.5 Kg (approx) (with accessories)
Accessories
Standard
3m Test lead Set (3mA) : 1 Set
10m Test lead Set (6mA) : 1 Set
Mains Power Cord : 1 Set
Mains Protected Fuse : 2 No.
RS232 Communication cable : 1 No.
Instruction Manual : 1 No.
Calibration Certificate : 1 No.
Carry Case : 1 No.
Pen Drive : 1 No.
USB 2.0 A/B Cable 1.5 mtr long : 1 No
