Measurement Mode: TDR Mode & BRIDGE Mode
TDR Mode:
Fault Distance: 16 Km (240m, 480m, 1000m, 2000m, 4000m, 8000m, 16000m)
Range: 0 to 16 Km
Fault Accuracy: 1 Meter
Pulse Width: 40 ns - 10 us
Pulse Waveform: Two polarity pulse
Pulse Amplitude: 0-30V Adjustment adaptive
VOP Range: 100 - 300
Impedance Matching: Automatic
Gain Adjustment: Automatic and Manual
Testing Accuracy: +1% x Cable length
Measurement Dead Zone: 0 Meter
Auto Measurement Dead Zone: 0 Meter
Output Impedance: 25 - 120 ohms (Adaptive)
Sampling Speed : 100 MHZ
PC Connectivity: USB
Resolution : 1 Meter
Gain Range: 1-99 dB
Display Readout: Color LCD and 480 * 280
BRIDGE Mode:
The max Length of Testing Cable: 10 km
Max Poor Insulation Resistance: 100 MΩ
Maximum Resistance of Defective Insulation: 100 MΩ
Power Supply: 7.4 V Rechargeable Li-on battery
Charging Time: 3 Hours
Operating Time: 8 Hours
Charging Voltage: 230V AC + 10%, 50Hz, Single phase.
Storage Temp.: -15℃ ~ +55℃
Working Temp.: -15℃ ~ +45℃
Dimension: 212mm(L) x 170mm(W) x 90 (H)mm
Weight: 1.27 Kg Approx
Standard Accessories:
Carrying Case
Re-chargeable battery charger / Adapter
Connecting Test Cables
Softrware CD
8 GB Pen Drive
Instruction / User Manual
