Test Frequency: 20 Hz-500kHz, 0.01Hz resolution
Test Parameter: | Z|, |Y|, C, L, X, B, R, G, D, Q, θ,DCR
Basic Measurement Accuracy 0.05% 0.05%
Equivalent Circuit : Series , Parallel
Range Mode: Auto, Hold, manual
Trigger Mode : Internal, Manual, External, Bus
Test Speed(≥1kHz):
Fast: 75 time/sec.,
Med: 12 time/sec.,
Slow: 3 time/sec.
Fast: 75 time/sec.,
Med: 12 time/sec.,
Slow: 3 time/sec.
Delay Time: 0-60s, 1ms
Output Empedansı: 30 Ω, 50 Ω,100 Ω, 10 /CC selectable
Display Range:
| Z|, R, X: 0.01mΩ-99.9999 MΩ
|Y|, G, B: 0.00001µS-99.9999S
L: 0.00001µH-9999.99H
Q: 0.00001-9999.9
DCR: 0.001 mΩ-99.9999 MΩ
C: 0.00001pF-9.9999F
D: 0.00001-9.9999
θ(RAD): -3.14159-3.14159
θ(DEG): -179.999º-179.999º
Test Level : Normal:5mV-2 V Accuracy:%10, with step of 1 mV; Constant level:10mV-1 V Accuracy:%5, with step of 1 mV
