Maximum test force: 100KN
Test frequency: 0.3-5Hz
Test amplitude: ±100mm
Amplitude resolution: 0.1mm
Counter capacity: 9*10 times
Counting stop accuracy: ±1
Preload stroke: Not less than 200mm
Maximum length of test piece: 2000mm
Power supply voltage (three-wire four-phase system): 380VAC 50Hz
Gas source: Compressed air pressure≥0.5MPa
Motor power: 22kW
Weight: 10000kg
Testing machine electrical equipment quality, assembly quality, appearance quality: Should comply with GB/T2611-2006 General Technical Requirements for Testing Machines
Maximum width of leaf spring assembly: 200mm
Clamping space height of leaf spring assembly (arc height + thickness): 200-300mm
