Image Sensor: 752 × 480 CMOS
Illumination: White LED
Decoding Capability: 1D, 2D (QR Code)
Resolution: ≥ 5 mil
Scanning Modes: Sense Mode, Continuous Mode
Light Source: LED (622 nm – 628 nm)
Minimum Print Contrast: 25%
Scan Window: 38.3 mm × 60.4 mm
Field of View: Horizontal 75°, Vertical 50°
Scan Angle: Roll 360°; Pitch ±40°; Skew ±40°
Dimensions (W × D × H): 78.7 × 67.7 × 62.5 mm (maximum)
Weight: 184 g
Indication: Beep sound
Power Consumption: 572 mW (typical)
Operating Voltage: 5VDC ±5%
Current: Operating: 115 mA (typical); Maximum: 198 mA
Interface: RS-232, USB
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-4°F to 158°F)
Humidity: 5% – 95% (non-condensing)
ESD Protection: ±8 kV (air discharge); ±4 kV (direct discharge)
