Number of Axes: 3 axes
Maximum Working Area (X/Y/Z): 350/400/100 mm (14/16/4 in.)
Workpiece Payload: 25 kg (55 lb)
Tool Payload: 8 kg (18 lb)
Maximum Speed (per second): 500/250 mm/giây (20/10 in.)
Unit Weight: 55.5 kg (122 lb)
Dimensions (WxHxD): 820x652x737.5mm (32x26x29 in.)
Drive System:
Closed Loop
Stepping Motor and Driver Package with Absolute Encoder
Memory Capacity: PC Storage
Data Storage: PC Storage
General Purpose I/O: 8 inputs/8 outputs (16/16 optional)
Drive Method: PTP and CP
Power Supply: Auto-switching, AC100–240 VAC, 380 W
Interpolation: 3 axes (3D space)
Repeatability: ±0.01 mm
Working Temperature: 10–40 °C (50–104 °F)
Closed-loop Motor System: Included
Tip Detection System: Included
High-precision Vision: Included
Laser Height Detection: Optional
Simple Vision System: N/A
