Application:For measurements of solid components. e.g. heavy castings and forgings
Indenter type:Tungsten carbide
Test object requirements
+ Minimum sample weight:
Of compact shape: 15 kg (33 lbs).
On solid support: 5 kg (11 lbs).
Coupled on plate: 0.5 kg (1.1 lbs).
+ Minimum sample thickness:
Uncoupled: 70 mm (2.73 inches).
Coupled: 10 mm (0.4 inches).
+ Material: low, fine and medium grained ferrous and non-ferrous metals
Measuring range
HLG: 300-800
HRC: 20~61
HB: 90~650
HV: 230~800
Tensile strength, MPa: 370~1740
User calibrations for any range (for example: HV10-940)
Measurement accuracy
HLG: ±10
HRC: ±2
HB: ±10
HV: ±15
Scales
Precalibrated for HRC, HRA, HRB, HB, HV, MPA
Can be calibrated for any other (Shore HS, etc.)
Materials
Precalibrated for steel, alloy steel, cast iron, stainless steel, aluminum, bronze, brass, copper
Can be calibrated for any other
Standard:ASTM A956
Compatible models:T-UD3 (Lab), T-D3 (Lab), T-UD2 (Lab), T-D2 (Lab)
Operating environment
Temperature: -20°C ~ 50°C
Humidity: 30% ~ 80% R.H
Weight (with cable), g:255
Dimensions, mm:254*30
