Thickness measurement range(depends on probe type): 0 µm … 60 mm
Measured parameter: coating thickness, corrosion depth, roughness, temperature, humidity, dew point temperature
Measuring units: μm, mm, inch, mil
Revision modes: calculation of average, indication of minimum and maximum
PC connection: yes
Menu languages: English, Spanish, French, Russian
Dimensions, mm: 122x60x25
Operating temperature range, °C: -20 … +40°C
Batteries: 2 AA
Type of connectors of probes: Lemo
Storage of measurement results and PC software (optional): 256
Time of continuous work hours, not less: 20
Weight of electronic unit with batteries, no more, kg: 0.2
Standard package:
- Thickness gauge electronic unit TP-2020
- Standart probe ( by customer’s choice)
- Set of reference thickness samples
- Batteries (AA) – 2 pcs
- Charger
- USB cable
- Operating manual
- Case
Optional Probes:
- Probe F-0.3 – 0-300μm. Measurement of paint, varnish and galvanic coatings
- Probe F-0.5 – 0-500μm. Measurement of paint, varnish and galvanic coatings
- Probe F-2 – 0-2000μm. Measurement of paint and varnish coatings
- Probe F-5 – 0-5000μm. Measurement of paint, varnish and mastic coatings
- Probe NF-2 – 0-2000μm. Measurement of anodic-oxide films and paint coatings
- Probe M-12 – 0-12 mm. Measurement of mastic coatings
- Probe M-30 – 0-30 mm. Measurement of mastic coatings
- Probe M-60 – 0-60 mm. Measurement of mastic coatings
- Probe DSH-2-300 μm – Measurement of surface roughness after sand and shot blasting
- Probe DT– Temperature measurement
- Probe DTVR – Measurement of temperature, humidity and dew point
Description:
Coating thickness gauge NOVOTEST TP-2020 is designed for thickness measuring of coatings based on ferrous and non-ferrous metals. Variety of various sensors make it possible of non-destructive testing of protective coatings with a wide thicknesses range. Thickness gauge can also measure next parameters: the depth of grooves and corrosion, surface roughness as well as temperature control, ambient humidity and dewpoint temperature, therefore covering a wide range of tasks by one universal unit (thickness gauge).
Advantages:
- Measures coating thickness on ferrous (Fe) and non-ferrous (nFe) metals
- Automatic sensor detection
- Wide range of sensors for different tasks
- Selecting units of measure
- Storing individual calibrations in probes memory
- Average calculation, minimum and maximum indication
- High measurement accuracy
- Transfer of measurement data to PC via usb
- Portability
- Large buttons
- Enlarged screen
- Shockproof housing with a special protective silicone bumper case
- Charge control
