NXP NX3L2467PW,118 Analog Switch ICs DUAL LO-OHMIC DBL-PL DBL-THROW ANALOG SW
Manufacturer: NXP Model: NX3L2467PW,118 - Contact
Supply Type: Single Supply
Unit Weight: 85.186 mg
Configuration: 2 x DPDT
On Time - Max: 40 ns
Mounting Style: SMD/SMT
Off Time - Max: 20 ns
Number of Channels: 4 Channel
On Resistance - Max: 750 mOhms
Supply Current - Max: 150 nA
Supply Voltage - Max: 4.3 V
Supply Voltage - Min: 1.4 V
Switch Voltage - Max: 4.3 V
Pd - Power Dissipation: 250 mW
Operating Supply Voltage: 1.4 V to 4.3 V
Switch Continuous Current: 350 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
