GENERAL
Measures from 0.001 mm (0.0001 in.) to 25.4mm (1 in.)
Overall dimensions: 236 mm x 167 mm x 70 mm (9.3 in. x 6.57 in. x 2.76 in.)
Weight: 1.68 kg (3.72 lb), including lithium-ion battery
Keypad: English, Japanese, Chinese, International
Languages: English, Spanish, French, German, Japanese, Chinese, Portuguese, Swedish, Norwegian, Dutch, Polish, Russian, Hungarian, Czech, Italian
Data storage: Onboard and removable 2 GB microSD™ card
Battery life (Optional): 16 h (lithium-ion)
Power requirements: AC Mains: 100 VAC to120 VAC, 200 VAC to 240 VAC
Display type: Full VGA (640 x 480 pixels) transflective color LCD
Display dimensions (W x H, Diag.): 117 mm x 89 mm, 146 mm (4.62 in. x 3.49 in., 5.76 in.)
Min/max capture mode: Captured at 60 Hz measurement rate
Display update rate: 4, 8, 16, and 20 Hz
Alarm: High and low alarms
Resolution: 0.1 mm (0.01 in.), 0.01 mm (0.001 in.), 0.001 mm (0.0001 in.) (depending on thickness range)
Probes
86PR-1: Standard straight probe 82.30 mm (3.24 in.) long and 18.62 mm (0.733 in.) dia.
86PR-2: Right angle probe head 58.84 mm x 18.62 mm, length 178.57 mm (2.32 in. x 0.733 in. dia., length 7.030 in.)
86PR-3: Low-profile articulating probe 241.3 mm (9.5 in.) long
Environmental Testing
Vibration: MIL-STD-810G, Method 514.6, Procedure I
Drop: MIL-STD-810G, Method 516.6, Procedure IV
Shock: MIL-STD-810G, Method 516.6, Procedure I
Designed for IP67: Yes
Inputs/Outputs
USB: USB 2.0 peripheral port
RS-232: Yes
Memory card: Maximum capacity: 64 GB removable microSD memory card
Video output: VGA output standard
Foot switch (optional): Programmable (Save, Send, Meas or Q-Cal)
Operation temperature: –10°C to 50°C (14°F to 122°F)
