Width: 17.7 mm
Height: 90 mm
Length: 1102 mm
Accuracy: ± 0.35 %, ± 0.1 %
Mounting: DIN Rail 32 mm Standard or 35 mm
Approvals: CE
Isolation: 1800 Vdc
Standards: IEC 801-2, Level 2
Case Style: A
Input Type: Voltage, Current (bipolar)
Overvoltage: Voltage: 400 Vrms, Current: 60 Vdc
Accuracy Note: Accuracy (including linearity, hysteresis):<2 mA/20 mV: ±0.35% fs, typical; 0.5% max.; >2 mA/20 mV:±0.1% fs typical, 0.2% max.
Output Signal: Voltage
Response Time: 200 msec
Supply Voltage: 9 to 30 Vdc
Impedance Input: Voltage: >100 kΩ, Current: 20 Ω
Number of Inputs: 2
Electrical Output: 0 to 1 mA, 0 to 20 mA, 4 to 20 mA
Relative Humidity: Operating: 15 to 95% (@45°C), Soak: 90% for 24 hours (@65°C)
Supply Power Note: 9-30 Vdc, 1.5 W typical, 2.5 W max
Supply Power Type: DC
Excitation Current: < 2 mA for Pt100, Pt500, Pt1000; <5 mA for Cu100; <10 mA for Cu10, Cu25
Response Time Note: (10 to 90%) 200 mS., typical
Voltage Output Range: ± 5 V, ± 10 V
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -25 °C
Current Measurement Range: 2 mA, 5 mA, 10 mA, 20 mA, 50 mA, 100 mA
Voltage Measurement Range: 20 mV, 50 mV, 100 mV, 200 mV, 500 mV, 1V, 2V, 5V, 10V, 25V, 50V, 100V
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
