OMEGA SP-001-0 Smart IR Sensor -70 °C to 380 °C Temperature (Temperature, 6:1)

Length: 67 mm

Weight: 35 g

Accuracy: ± 4 °C (± 7.2 °F)

Diameter: 12 mm

Software: Compatible with OEG and SYNC configuration software

Approvals: CE, UKCA

Vibration: 10 Gs from 10 Hz to 500 Hz

Accuracy Note: Temperature Accuracy @ Ambient of 0 to 50°C(32 to 122°F): 1°C (1.8°F) or 1% of reading, whichever is greater Accuracy Over Entire Ambient Operating Range: 4°C (7.2°F) or 3% of reading, whichever is greater

Configuration: Configurable via SYNC configuration software

Field of view: 6:1

Number of I/O: 0

Repeatability: Temperature: 1°C

Thread Length: 33.5 mm

Supply Voltage: 3.3 Vdc

Emissivity, Max: 0.01 to 1.00

Thread Diameter: 12 mm

Measurement Type: Temperature

Enclosure Ratings: IP67, NEMA Type 6

Relative Humidity: 0 to 95% RH

Supply Power Type: DC

Enclosure Material: Stainless Steel

Number of Channels: 2

Repeatability Note: Temperature: 1°C (1.8°F) or 1% of reading

Spectral Response, Max: 14 µm

Spectral Response, Min: 5.5 µm

Process Connection Type: Internal

Process Temperature, Max: 380 °C

Process Temperature, Min: -70 °C

Temperature Response Time: 1 sec

Operating Temperature, Max: 85 °C

Operating Temperature, Min: -40 °C
