Bluetooth Module
DC Voltage: 6.000V/60.00V/600.0V/1000V
Resolution: 0.01mV/ 1V
Accuracy: ±(0.5%+2dig)~±(0.8%+2dig)
AC Voltage: 6.000V/60.00V/600.0V/750V
Resolution: 0.1mV/ 1V
Accuracy: ±(0.8%+3dig) ~ ±(1%+3dig)
DC Current: 60.00uA/600.0μA/60.00mA/600.0mA/20A
Resolution: 0.01μA ~ 0.01A
Accuracy:±(0.8%+2dig) ~ ±(1.2%+3dig)
AC Current: 60.00uA/600.0μA/60.00mA/600.0mA/20A
Resolution: 0.01μA ~ 0.01A
Accuracy:±(1%+3dig) ~ ±(1.5%+3dig)
Resistance 600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ/60.00MΩ
Resolution:0.1Ω~0.01MΩ
Accuracy:±(0.8%+2dig)
Capacitance: 60.00nF~60mF
Resolution: 0.01nF~0.1μF
Accuracy: ±(2.5%+3dig) ~ ±(3%+5dig)
Input Protection
Auto-scale
Dimension (W×H×D) 196 x 88.5 x56 (mm)
Weight (without package) 0.3kg
