Sensor: 120´90
Temperature range: -20°C ~400°C
Accuracy: -10℃~400℃，the accuracy is ±2C or 2%; take the maximum value (normal temperature 25℃ )
Resolution ratio: 0.1℃
Mode: Automatic gain
The best measurement distance: 50cm
Temperature measurement response time: ≤500ms
Emissivity: 0.95 (default)(adjustable from 0.1 to 0.99)
Pixel size: 17μm
Palette: Iron red, rainbow, white heat, black heat, red heat
Infrared spectral bandwidth: 8~14μm
Field of View Angle（FOV): 50°（H)*38°（V)
Instant Field of View Angle（FOV): 7.3mrad
Thermal imaging sensitivity: ≤60mK
Frame rate: ≤25Hz
Temperature measurement display: Main area temperature measurement (ROI), central point temperature measurement, high and low temperature tracking
Image format: BMP
Visible light resolution: 640*480
Field of View Angle（FOV): 81 degree
Image mode: Thermal imaging,digital camera(visible band temperature display), integration
Thermostat alarm: Image alarm, LED alarm and buzzer alarm
Auto shut off: Optional (5min 10min 30min off) The default is 30min
Data communication: Type-C USB
Battery: Li-ion 3.7V/5000mAh
Display: 2.8”TFT LCD（320*240）
