Specification
Measuring range: 0 ... 200 N / 0 ... 45 lbs
Calibration:0.1 N / 0.02 lbs
Pressure calibration:1 Mpa
Load cell:Integrated load cell with M6 connection
Measuring range:1 ... 100% of the full scale
Measurement accuracy:± 0.5%
Units:n, kg, lb
Display:LCD
Operating temperatur:10 ... 30°C / 50 ... 86°F
Relative fencing:15 ... 80% relative humidity
Working conditions:The device must not be located near sources of vibration or corrosive substances
Weight:1 kg / 2.2 lbs
Delivery contents
1 x Dynamometer PCE-PTR 200N
1 x Instructions for the penetrometer
1 x Penetration tip of Ø 6 mm / 0.2 in
1 x Penetration tip of Ø 8 mm / 0.3 in
1 x Penetration tip of Ø 11 mm / 0.4 in
2 x Locking rings
1 x Conversion table
1 x Evaluation software
1 x USB cable
1 x Charging adapter
1 x Carrying case for the dynamometer
