Luminous intensity test range: 0.1-30000cd
Accuracy of photometry: class 1
Beam spread angle: θ(50%)θ(25%)θ(75%)
Angle range: -90~+90 degrees
Accuracy of angle: ±0.2 degrees
Angle interval: 0.5/1/1.5 degrees
Detector: V（λ）correction
RS-232 port, work under the system of Windows 2000/xp
Max lamp size: 18cm
Test distance: 1000mm/316mm
Can output IES file
PG-1200A luminous intensity distribution test system is applied to test the total luminous flux, isocandela diagram, isolux diagram, IES file and other photometry data. Equip with dark chamber and light diaphragm, the dark room is needless. The test system is applied to test LED reflection lamp fixture, meet the requirements of LM-79, IEC and CIE121.
