Ratio: 1000:1
Input Resistance: 900MΩ
Input Capacitor: 2.0PF
Max. DC + AC peak: 39KV CAT II
Max. AC RMS: 27KV CAT II
Max. Loading Current: 45uA
Bandwidth: DC~50MHz
Rise time: 7 nS
Noise: >60dB at 1KHz; >50dB at 1MHZ
Temp. Coefficient: ≦200 PPM/℃
Compensation Range: 10PF~35PF
Cable length: 2m
Operation Temp.: -10~55 ℃
Humidity: 85% RH or less(at 35℃)
Weight/Volume: 460g /80(W) x 80(H) X 320(L) mm
