SPECIFICATIONS
Power : 30kW
Output Voltage : 0~100V
Output Current : 0~300A
Input Phase : 3 Phase, 3 Wire+G
Input Voltage : 380 VAC / 400 VAC / 415 VAC / 440 VAC / 480 VAC ±10%, 3Φ
Input Frequency : 47-63 Hz
Power Factor : >0.9 at Max power
Efficiency : >87%
Line regulation : <0.3%
Load regulation : <0.3%
Voltage Ripple (rms) : <0.5%
Voltage Noise(p-p) : <3.7%
Voltage Slew Rate : ≤65ms
Transient Response : ≤ 4-12ms
Voltage & Current Measurement Accuracy : <0.5% FS
Voltage & Current Resolution : 0.1V/0.1A
Remote Interface : RS-485 (Opt.: GPIB / RS-232)
Protection : Vin OVP, Vin UVP, OVP, OCP, OTP
OVP Adjustment Range : 5%-115% from front panel
OVP Accuracy : 1% of full-scale output
OCP Adjustment Range : 5%-115% from front panel
OCP Accuracy : 1% of full-scale output
Remote Sense Limits : 3% maximum voltage drop from output to load (For models ≦1000 Vdc
Operating Temperature : 0℃～40℃
Storage Temperature : -20℃～70℃
Isolation : Input to Enclosure 2000Vac
Dimension (H*W*D) : 41.5 x 23.6 x 31.5 inches /1050 x 600 x 800 mm
Weight : 496lbs/225kg
