PRODIGIT D3000 Programmable DC Power Supply (3000W)
Manufacturer: PRODIGIT Model: D3000 Origin: Taiwan Guarantee: 12 Month - Contact
Input voltage range: 170-265Vac (1Φ), 47-63Hz
Max. output power: 3000W
Output voltage range: 0 ~ 600Vdc
Output current range: 0 ~ 6A
Operation mode: CV / CC
Voltage rise time: < 150ms (rated load by fixed resistor)
Voltage fall time: < 150ms (full load) < 3s (no load)
Protection: OVP, UVL, OCP, OPP, OTP, SCP, Fan Lock
Operating temperature: 0 ~ 50°C
Cooling system: Fan Cooling
Dimensions (L x W x H): 437.8 x 422.8 x 43.6 mm
Weight: 8.8 Kg
AC input connector: RS232, RS485, GPIB
