Power consumption: 80W
The output voltage: AC 5.6KV
Ion balance: Adjusted to within ±15V at the factory (450mm from the panel)
Air volume: ≤1.2-2.4 m3/min
Ozone production: 0.03ppm or less (150mm from the middle of the air outlet)
Operating temperature: 0-50 ° C
Effective range: 600 × 1600mm
filter device: Option
External size: 1086(L) × 170(W) × 90(H)mm
weight: About 9.0 kg
Features:
1. Produce a wide range of ion currents.
2. The ion balance is stable and adjustable.
3. With hanging installation, it can save a lot of space.
