Metrological parameters:
E1 Calibration Range: 0.05 – 500 mg
E2 Calibration Range: 0.05 – 500 mg
F1 Calibration Range: 0.05 – 500 mg
F2 Calibration Range: 0.05 – 500 mg
Maximum capacity [Max]: 510 mg
Readability [d]: 10 ng
Standard repeatability [5% Max]: 0.04 µg
Standard repeatability [Max]: 0.06 µg
Permissible repeatability: 0.1 µg
Eccentricity (tested load): 0 mg
Electric compensation range: 0 – 510 mg
Stabilization time: 30 s
Adjustment: external
Physical parameters:
Display: 10″ graphic colour touchscreen
Weighing pan dimensions: ø20 mm
Weighing device dimensions: 385×245×390 mm
Controling device dimensions: 460×250×195 mm
Packaging dimensions: 860×750×570 mm
Net weight: 21 kg
Gross weight: 31 kg
Supplementary weights internal: -
Supplementary weights external: -
Magazine positions: 4
Communication interface:
Communication interface: 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot
Electrical parameters:
Power supply: 100 – 240 V AC 50/60 Hz
Environmental conditions:
Operating temperature: +15 – +30 °C
Operating temperature change rate: ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity: 40% – 60%
Relative humidity change rate: ±5% / 12 h (3% / 4 h)
