Build Volume
Single Extruder Print: 330 × 240 × 240 mm (13 × 9.4 × 9.4 inch)
Dual Extruder Print: 295 × 240 × 240 mm (11.6 × 9.4 × 9.4 inch)
Machine Size (W × D × H): 607 × 596 × 465 mm (23.9 × 23.5 × 18.3 inch)
Weight
Net Weight: 35.1 kg (77.4 lbs)
Gross Weight (Carton Only): 43.8 kg (96.6 lbs)
Gross Weight (Carton with Pallet): 51.3 kg (113.1 lbs)
Electrical
Power Supply Input: 100–240 V AC, 50/60 Hz 230 V @ 2 A
Power Supply Output: 24 V DC, 350 W
Print Technology: Fused Filament Fabrication (FFF)
Print Head System: IDEX Independent Dual Extruders
Filament Diameter: 1.75 mm
XYZ Step Size: 0.78125, 0.78125, 0.078125 micron
Print Head Travel Speed: 15–150 mm/s
Build Plate: Flexible Steel Plate with BuildTak
Max Build Plate Temperature: 110℃
Heated Bed Material: Silicone
Build Plate Leveling: Mesh-leveling with Flatness Detection
Filament Run-out Sensor: Available
General
Layer Height: Compatible with 0.2, 0.4, 0.6, 0.8, 1.0 mm nozzles (recommended 0.1–0.3 mm for best results)
Nozzle Diameter: 0.4 mm (Default), 0.6/0.8 mm (Available)
Hot End: V3P
Max Nozzle Temperature: 300℃
Connectivity: Wi-Fi, LAN, USB Port, Live Camera
Noise Emission (Acoustic): < 50 dB (A) when building
Operating Ambient Temperature: 15–30℃, 10–90% RH, non-condensing
Storage Temperature: –25℃ to +55℃, 10–90% RH, non-condensing
Filter: HEPA Filter with Activated Charcoal
Technical Certifications: CB, CE, FCC, RoHS, RCM
Material
Material Type: PLA/ ABS/ ASA/ PETG/ PC/ PETG ESD/ TPU 95A/ PVA+
Third Party Material: Supported by Raise3D OFP (Open Filament Program)
Software
Slicing Software: ideaMaker
Supported File Types: STL/ OBJ/ 3MF/ OLTP
Supported OS: Windows/ macOS/ Linux
Machine Code Type: GCODE
Printer Controller
User Interface: 7-inch Touch Screen
Network: Wi-Fi, Ethernet
Power Loss Recovery: Available
Screen Resolution: 1024 × 600
Motion Controller: Atmel ARM Cortex-M4 120 MHz FPU
Logic Controller: NXP ARM Cortex-A9 Quad 1 GHz
Memory: 1 GB
Onboard Flash: 16 GB
Embedded Linux OS
Ports: USB 2.0 × 2, Ethernet × 1
