Frequency Range: 9 kHz to 12 GHz
Frequency Resolution: 0.001 Hz
Frequency Switching Time: ≤ 1ms (typical)
Reference Output:
Frequency: 10MHz
Power: >+4dBm, to 50Ω load
Reference Input:
Frequency: 1MHz – 50MHz, step 1Hz
Power: 0dBm to +7dBm, impedance 50Ω
Scanning Mode: Step scan, List scan
Scan Dwell Time: 100μs – 100s
Minimum Output Power:
Standard: -15dBm (can be set -20dBm)
Option H01: -110dBm (can be set -135dBm)
Maximum Output Power (Standard):
9kHz ≤ f ≤ 3GHz: 16dBm
3GHz ＜ f≤ 20GHz: 15dBm
Power Resolution: 0.01 dB
VSWR (typ.)
9kHz ≤ f ≤ 3GHz: <1.7
3GHz ＜ f ≤ 13GHz: <1.6
13GHz ＜ f ≤ 20GHz: <1.8
20GHz ＜ f ≤ 40GHz: <1.6
Maximum Rerverse Power: 0.5W (0V DC) (rated value)
Haimonic Wave (at +10dBm)
9kHz ≤ f ≤ 10MHz: < -23dBc
10MHz < f ≤ 2GHz: < -30dBc
2GHz ＜ f ≤ 6GHz: < -30dBc (S1435B)
2GHz ＜ f ≤ 20GHz: < -55dBc
20GHz ＜ f ≤ 40GHz: < -50dBc (typ.)
SSB Phase Noise (Carrier 1GHz, at +10dBm): Standard:
≤-83 dBc/Hz @ 100Hz offset
≤-115 dBc/Hz @ 10kHz offset
RF Output Port: N type (female), impedance 50Ω
Power Consumption: < 300W
Dimension (max.)
330 (W) × 147 (H) × 397 (D) mm (excluding the handle)
420 (W) × 147 (H) × 445 (D) mm (including the handle)
Weight: < 12kg
Power Supply: 100 – 120VAC, 50 – 60Hz; or 200 – 240VAC, 50 – 60Hz (self-adaptive)
