1. OTDR
Wavelength: 1310/1550nm
Dynamic Range: 37/35 dB
Event Blind Zone: 0.8m
Attenuation Blind Zone: 5m
Display Resolution: 0.01dB
Test Range: 0.1/0.3/0.5/1.25/2.5/5/10/20/40/80/160/260/420km
Pulse Width: 3ns/5ns/10ns/20ns/30ns/50ns/80ns/100ns/200ns/300ns/500ns/800ns/1us/2us/3us/5us/8us/10us/20us
Sampling Point: 3.2k-320k
Sampling Resolution: 0.03125m – 8m
Loss Resolution: 0.001dB
IOR: 1.00000 – 2.00000, 0.00001 step
Loss Analysis: 4-point method/ 5-point method
File Format: .SOR (standard format)
Optical Interface: FC/UPC (Interchangeable SC, ST)
Laser Safety Level: Class II
Refresh Rate: 10Hz (typ.)
Multitasking Function: Support
Connection Detection: Support
Remote Assistance: Support
2. OPM
Wavelength Range: 800nm – 1700nm
Measurement Range: (-50dBm to +26dBm) or (-70dBm to +10dBm)
Uncertainty: ± 5%
Resolution: ≤ 0.01dB
Connector: Universal joint FC/SC/ST
Calibration Wavelength: 850/980/1300/1310/1490/1550/1625/1650 nm
3. LS
Wavelength: Consistent with OTDR output wavelength
Stability: CW, ±0.5dB/15min
Laser Source: FP-LD
Connector: FC/UPC (Interchangeable SC, ST)
Output Mode:CW/270Hz/330Hz/1kHz/2kHz
4. VFL
Wavelength: 650nm ± 20nm
Output Power: ≥ 10mW (standard)
Mode: CW/1Hz/2Hz
Connector: FC/UPC (Interchangeable SC, ST)
Laser Safety Level: Class III
5. Laser Ranging
Test Range: 0.05m – 40m
Test Accuracy: ± 2.0mm
Laser Type: 620nm – 690nm
6. RJ45 Cable Tracker
Mode: Digital / Analog tracking
Test Distance: ≥ 300m
Unique Functions: Support online tracking and line pair tracking
7. Optical Loss Test
Wavelength: Consistent with LS output wavelength
Test Range: Consistent with OPM
Insertion Loss Test: Support
Display: 7 inch 1024×600 IPS TFT-LCD, Multi touch capacitive touch screen
Data Storage: Internal: 8GB (≥200,000 data)
Data Interface: 2 USB-A, 1 Mini-USB, 1000M Ethernet port, RJ45 tracker port, 3.5mm audio port
Battery: 7.4V / 6400mAh Lithium battery, max. 20 hours working time
Power Supply: AC/DC adapter: Input 100V-240V, 50/60Hz, 0.6A, Output 12V-19V, 3A
Camera: 5.000.000X
Dimension: 252 (W) × 180 (H) × 72 (D) mm
Weight: 1.5kg (including battery)
