Frequency Range: 50 MHz to 26.5 GHz
Power Range:
Normal: -30dBm ~ +20dBm (50MHz – 500MHz); -35dBm ~ +20dBm (≥ 500MHz)
Avarage: -45dBm ~ +20dBm
Rise/Fall Time: ≤ 13ns
Sampling Rate: 80M Samples/sec, continuous
Video Bandwidth: ≥30MHz
Pulse Width: Minimum 50ns
Accuracy: ≤±0.25dB (±6.0%)
Maximum SWR:
1.20 (50MHz - 2GHz)
1.26 (2GHz - 18GHz)
1.35 (18GHz - 26.5GHz)
Connector: 3.5mm(m)
Dimension (W×H×D): 133.9mm × 52.0mm × 34.0mm
Weight: < 0.3kg
