Feature & Use
* High travel of test anvil in vertical direction and it is suitable for testing of large test piece
* Manual testing process, no need for electric controlling
* It's steady and reliable for testing of curved surface
* Precision conforms to GB/T 230.2, ISO 6508-2 and ASTM E18
It's suitable to determine the Rockwell & Superficial Rockwell hardness of ferrous metals, alloy steel and hard alloy, as well as treated layers of metal surface, such as carburized layer, nitrided layer and electroplated coating, etc. It's especially suitable to determine heterotypic workpiece.
Specifications
Measuring range:20-88HRA, 20-100HRB, 20-70HRC
Test force: Rockwell 588.4, 980.7, 1471N (60, 100, 150kgf)
Max. height of test piece: 400mm
Depth of throat: 160mm
Min. scale value: 0.5HR
Dimensions: 548 x 326 x 1025mm
Weight: approx. 140kg
Standard accessories
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Diamond cone penetrator: 1 pc.
1/16" steel ball penetrator: 1 pc.
Rockwell standardized block: 5 pcs.
