I. Main technical features
1. It adopts integral structure. Easy to use and good-looing.
2. It adopts light-touch and digital display technology. The data set is easy and the timing shows strikingly. It stops automatically after the timing is over.
3. It equips a flowmeter to control and show the flow rate of air suction.
4. The accessories are fully equipped. It equips two vacuum bottles to control the air suction. It can meet standard SH/T 0248-2006.
5. The instrument can be singly used to do CFPP determination equipping with suitable cooling bath. It can also be used to do CFPP determination equipping with suitable low temperature tester.
II. Main technical specifications
1. Power supply: AC 220V±10%, 50 Hz
2. Pumping pressure: 1961 Pa (200 mm H2O)
3. Test cup: Glass, flat bottom, circular type; inner diameter
31.0～32.0 mm; Thickness 1.0～1.5mm; Height 115～125mm
There is a mark line at 45 ml of the cup.
4. Filter assembly: It is made of cooper; Size of hole on the filter sieve is 45 μm (330 meshes)
5. Working environment: (1) Ambient temperature: -10～+35℃ (2) Relative humidity: ≤85%
6. Maximum power consumption: 150 W
7. Dimension: 250mm×150mm×380mm（Vacuum bottles are not included）
