Display: 16 Character x4 Line LCD
Password access: Provided for Configuration & User settings
Heater output: 1 Relay (15A max. load)
Pressure (auto steam): 1 Relay (5A max. load)
Output: Alarm output inbuild buzzer with 12VDC O/P (50 mA max. load)
Water level sensor: Provided for High level
Door open sensor: Provided Limit switch input (NO)
Temp. sensor: RTD-PT 100 (3 wire)
Temp. range: 0~200°C
Temp. Accuracy: ±0.1% of FS
Soak timer: 0~9999 mins / secs (user selectable)
Time count: Up/Down (user selectable) direction
Pressure: Auto calculating from temperature reading
Pressure range: 0~35 PSI/ 0~250kPa (user selectable)
Mounting: Panel mounting
Overall dimension: 96 x 96 x 85(W x H x D) mm
Cut out dimension: 90 x 90(W x H) mm
Operating environment: 0~50°C / 20~95%RH (non condensing)
Weight: ≈1kg
