INPUT
- Voltage: 100-120VAC/ 200-240VAC ±10% Auto Range
- Frequency: 50/60 Hz ± 5%
- Fuse: 10A / 250Vac Slow-Blow
AC WITHSTAND VOLTAGE
- Output voltage: 0-5.00 kVAC
+Resolution: 0.01 kVAC
+ Accuracy: ± (2% of setting + 5V)
- Output frequency: 50Hz/60Hz ± 0.1%, User Selection
- Output Waveform: Sine Wave, Crest Factor = 1.3 - 1.5 and output voltage > 300V
- Hi-Limit AC current: 0.10-99.99mA
+ Resolution: 0.01mA
+ Accuracy: ± (2% of setting + 6 counts)
- Lo-Limit AC current: 0.00-99.99mA
+ Resolution: 0.01mA
+ Accuracy: ± (2% of setting + 6 counts)
- Ramp time: 0.2-180.0s
+ Resolution: 0.1s
+ Accuracy: (0.1% of setting + 0.05 sec)
- Dwell time: 0, 0.2 - 60.0s (0=continuous)
+ Resolution: 0.1s
+ Accuracy: ± (0.1% of setting + 0.05 sec)
DC WITHSTAND VOLTAGE
- Output voltage: 0-6.00 kVDC
+ Resolution: 0.01 kVDC
+ Accuracy: ± (2% of setting + 5V)
- DC output ripple, Vrms: <5 % (6KV / 10mA at Resistive Load)
- Hi-Limit DC current: 0.02 - 10.00mA
+ Resolution: 0.01mA
+ Accuracy: ± (2% of setting + 2 counts)
- Lo-Limit DC current: 0.00-10.00mA
+ Resolution: 0.01mA
+ Accuracy: ± (2% of setting + 2 counts)
- Ramp time: 0.2-180.0s
+ Resolution: 0.1s
+ Accuracy: (0.1% of setting + 0.05 sec)
- Dwell time: 0, 0.2 - 60.0s (0=continuous)
+ Resolution: 0.1s
+ Accuracy: ± (0.1% of setting + 0.05 sec)
INSULATION RESISTANCE
- Output voltage VDC: 100-1000
+ Resolution: 1VDC
+ Accuracy: ± (2% of setting + 5V)
- Hi-Limit resistance, MΩ: 0, 1 - 1000 (0 = OFF)
+ Resolution: 1
+ Accuracy: 100-499V ± (7% of setting+ 2 counts)
- Lo-Limit resistance, MΩ: 1-1000
+ Resolution: 1
+ Accuracy: 500-1000V± (3% of setting+ 2 counts)
- Ramp time: 0.1 or 2.0s
+ Resolution: 0.1s
+ Accuracy: (0.1% of setting + 0.05 sec)
- Delay time: 0, 0.5 - 999.9s
+ Resolution: 0.1s
+ Accuracy: ± (0.1% of setting + 0.05 sec)
GROUND BOND
- Output AC current: 1.0 – 40.0A
+ Resolution: 0.1A
+ Accuracy: ± (2 % of setting+ 2 counts)
- Output AC voltage: 8V (Fixed)
- Output frequency: 50Hz/60Hz ± 0.1%, User Selectable
- Maximum loading: 1.0–10.0A/0–600mΩ,10.1–30.0A/0–200mΩ,30.1–40.0A/0–150mΩ
GENERAL SPECIFICATIONS
Memories: Allows storage of up to 20 different test programs and a single step mode
Remote I/O:
+ Input: Test, Reset, Interlock & Recall Memory 1 – 6
+ Output: Pass, Fail, Test-in-Process
Interface: USB (Optional)
Dimension: 430mm(W) ×132mm(H) × 400 mm(D)
Weight: 53lbs (24kg)
