Accuracy: ±0.5 %FS @ 25 °C
Applications: Only air and non-aggressive dry gases
Burst pressure: 6 x FS
Compensated temperature: 0…+50 °C
Connection (to meter): 4-pole M12
Connection (to process): For ⌀ 6x1 mm (internal ⌀ 4 mm) and ⌀ 8x1 mm (internal ⌀ 6 mm) hoses. 2 inputs for differential probes, 1 input for absolute probes
Dimensions: ⌀ 21.7 x 62 mm
Long-term stability: < 1 %FS / year
Material: Stainless steel
Operating conditions: -25…+85 °C / 0…95% RH non-condensing
Output: UART (TTL 3.3V)
Overall error: ±2.5 %FS over the whole compensated temperature range
Overpressure: 3 x FS
Power supply: 3.3 ... 6 Vdc
Protection degree: IP65
Storage temperature: -40…+125 °C
Warm-up time: 2.3 ms
Weight: 74 g approx.
Measuring range: -20.00 ... +20.00 mbar
Cable connection: M12A connector, 4-pin
Calibration: Factory adjustment with test protocol
Compensated temperature range: 0 ... +50 °C
Housing: Stainless steel
Option: 1 m PVC connection cable M12
Pressure connection: 2x connection for tube 6x1 mm (4 mm inner) or 8x1 mm (6 mm inner), differential
Protection: type IP65
Version: Interchangeable without loss of accuracy
Working temperature: -25 ... +85 °C
