Pressure connection: G1/8 inch port incl. connection for tube 6x1 mm (4 mm inner) or 8x1 mm (6 mm inner)
Set-Option: Device, incl. 1 m tube 6x1 PVC, case GKK 1002, factory calibration WPD5, not DAkkS accredited
Additional functions: Sea level correction, NULL/Tare function, AVR: Averaging over 2 s / 5 s / 10 s
Adjustment: Zero point and slope
Connections: one tube connection, interchangeable with G1/8 universal port
Dimensions: 108 x 54 x 28 mm without pressure connection
Display: 3-line segment LCD, additional symbols, illuminated (white, illumination time adjustable), overhead display on key press
Display units: hPa, mbar, bar, PSI, mmHg (Torr)
Error: max. (-20 ... 50 °C) ± 0.1 % FSS ± 0.5 % of value
Housing material: Break-proof ABS housing
Max. overload: 20000 hPa abs.
Measurement rate: Slow: 2.5 measurements per second, Fast: 25 measurements per second
Measurements: Absolute pressure
Operating conditions: -20 ... +50 °C; 0 to 95 % r.h. temporarily 100 % r.h.)
Precision typ. @ 25 °C: ± 0.02 % FSS +/-0.1 % of value (@ 25 °C)
Protection type: IP 67
Standard functions: Min / Max / Hold, auto-Power-Off-function / if activated, the product switches off automatically
Storage temperature: -20 ... +70 °C
Weight: 140 g incl. battery
Measuring range: 0 ... 14000 hPa (mbar)
Current supply: 2 x AA batteries
Working temperature -20 ... +50 °C
