Power supply
Supply voltage : 85..265 V AC/110..125 V DC
Frequency AC : 40..400 Hz
Power consumption : max. 2.2 W , max. 3.3 VA
Operating temperature : -10..+60 °C
CE-conformity : EN 61326-1:2013; EN 60664-1:2007
Input
13 ranges, switch selectable
- Sensor current : approx. 1 mA
Line resistance : max. 100 Ω
Accuracy : ≤ 0.2 %
Zero adjust : approx. ± 8 Ω ( ≙ 20 °C)
End value : adjustable approx. +/-20 %
Sensor error;
- broken or shorted line: output rises to max. output value
Outputs
Current : 0/4..20 mA switch selectable burden ≤ 1 kΩ
Voltage : 0/2..10 V switch selectable
load max. 15 mA , short-circuit-proof (simultaneously to the current output max. 5 mA)
Case : Polycarbonate, UL94V-; TS 35 acc. to DIN EN 60715:2001-09
Weight : approx. 200 g
Protection class : case IP30, terminals IP20, BGV A3
Electrical connection : screw terminals with pressure plate, max. 2.5 mm²
