Shinho X-50-M21 Handheld OTDR (850/1300 nm)

Technical parameter:

Testing Wavelength  (MM: ±20nm, SM: ±10nm): 850/1300

Dynamic Range (dB)[3]: 19/21

Event/Attenuation Dead-zone (m)[4]: 0.8/4

General specifications:

Dimension: 253×168×73.6mm; 1.5kg (battery included)

Display: 7 inch TFT-LCD with LED backlight (touch screen function is optional)

Interface: 1×RJ45 port, 3×USB port (USB 2.0, Type A USB×2, Type B USB×1)

Power Supply: 10V(dc), 100V(ac) to 240V(ac), 50~60Hz

Battery:

+ 7.4V(dc)/4.4Ah lithium battery (with air traffic certification)

+ Operating time: 12 hours [1], Telcordia GR-196-CORE

+ Charging time: <4 hours (power off)

Power Saving:

+ Backlight off: Disable/1 to 99 minutes

+ Auto shutdown: Disable/1 to 99 minutes

Data Storage: Internal memory: 4GB (about 40,000 groups of curves)

Language: User selectable (English, Simplified Chinese, traditional Chinese, French, Korean, Russian, Spanish and Portuguese-contact us for availability of others)

Environmental Conditions:
Operating temperature and humidity: -10 ~+50 , ≤95% (non-condensation)

+ Storage temperature and humidity: -2 ~+70, ≤95% (non-condensation)

+ Proof: IP65 (IEC60529)

Accessories:

+ Standard: Main unit, power adapter, Lithium battery, FC adapter, USB cord, User guide, CD disk, carrying case

+ Optional: SC/ST/LC adapter, Bare fiber adapter
