Open circuit output voltage:0.25－5kV ±5％
50Ω load output voltage: 0.125－2.5kV ±5％
Wave sharp of the pulse: 5/50ns，50Ω/1000Ωload
Rise time:
- 5ns ±30％，50Ω load
- 5ns ±30％，1000Ω load
Duration:
- 50ns ±30％，50Ω load
- 50ns －15/+100sn，1000Ω load
Impedance: 50Ω ±20％
Output polarity: Negative
Repetition frequency: 0.1－1200.0kHz ±10％
Burst duration Standard: 15ms@2.5kHz/5kHz,750μs@100kHz,250μs@300kHz
Burst duration Adjustable: Nos of pulse can adjust at 1-255. Burst duration=（pulse number-1）/repetition frequency
Burst period: 100－999ms
Burst mode: Synchronous or asynchronous
Synchronous phrase: Free set at 0－360° , resolution: 1°
Test function: IEC standard or set test mode freely (1000 groups)
Built-in coupling and decoupling network (3-phrase and 5 wires):
- AC: 3 phrase 380V,30A,50/60Hz
- DC: 380V,30A (Max)
Coupling mode: L1,L2, L3, N,PE,freely setup
Coupling capacitors: L1,L2, L3, N,PE,freely setup
Environment requirements: Temperature:15°C－35°C; Humidity: 10%－75%
Power requirements: AC220±10％,50/60Hz, 300W
Dimension: AC220±10％,50/60Hz, 300W
Weight: About 25kg
