Working Surface of Table (mm): 600x2000(24"x80")
Max.Table Travel (mm): 2230
Max.Cross Travel (mm): 660
Distance Between Table Surface and Spindle Center (mm): 600
Max.Table Load (kgs): 1500
Tee Slot (NumberXWidth) (mm): 3x16
Table Speed: (m/min): 7~25
Crossfeed Handwheel: 1grad (mm): 0.02
1rev (mm): 5
Automatic Crossfeed (mm): 0.5~12
Power Cross Feed: 50Hz (mm): 1250
60Hz (mm): 1500
Grinding Wheel (mm): 355x50x127
Spindle Speed: 50Hz (rpm): 1450
60Hz (rpm): 1740
Vertical Handwheel: 1grad (mm): 0.002
1rev (mm): 0.5
Automatic Down Feed Rate (mm): 0.005~0.04
Power Head Increment (mm): 230
Spindle Motor (kw): 7.5
Vertical Motor (kw): 370
Hydraulic Motor (kw): 5.5
Dust Collection Motor (w): 550
Coolant Motor (w): 90
Crossfeed Motor (kw): 370
Floor Space (mm): 6200x2700
Net Weight (kgs): 8500
Gross Weight (kgs): 9700
