Voltage/Current/Frequency
Measurement Range/Resolution/Accuracy
Vrms(AC+DC)
1~1000Vrms/ 0.1Vrms/ ±0.5% of nominal voltage
Vpk
1 ~ 1400Vpk/0.1Vpk/±0.5% of nominal voltage
V(Crest Factor)
1.0 ~ >2.8/ 0.01/ ±5%
Arms (AC)
10mV/A
0~100A/ 0.1A/ ±0.5%±0.2A
1mV/A
1~1000A/ 0.1A/ ±0.5%±0.2A
50mV(65mV)/1000A
15~5000A/ 1A/ ±1%±2A
A(Crest Factor)
1 ~ 10/ 0.01/ ±5%
Frequency
42.5~57.5Hz (50Hz nominal)/ 0.01Hz/ ±0.01Hz
51~69Hz (60Hz nominal)/ 0.01Hz/ ±0.01Hz
385~414Hz (400Hz nominal)/ 0.01Hz/ ±0.1Hz
Logger
Recording: user-defined parameters for 4 phases at the same time
Memory: Data stored in Micro SD card, 8GB
Duration Time: 2 hrs to 1 year, depends on the recording items and time interval
Interval: 1s to 60 minutes
Channel(Voltage/Current): 4/4
Voltage Range: 1-1000Vrms, 6000V transient voltage
Current Range: depends on supplied current clamp
Micro SD card(bulid-in): 8GB
Battery: NI-MH, 3800Ah/>7h
interface: USB Host, LAN
Screen: 5.6' TFT LCD with resolution320*240(SA2100)
Language: 10-Chinese, English, French, German, Korean, Polish, Portuguese , Spanish, Turkish,Russian
Dimension/Weigh: 262*173*66mm/1.6kg
