Applicable fibre
Material: Sillica glass
Cladding diameter: Φ 125 µm
Fibre count: Single to 12
Cleave length: 10mm; 6-20mm (Φ 0.25mm); 10-20mm(Φ 0.9mm)
Fibre placing: Fibre holder, Single fibre adapter(AP-FC8R)
Cleave angle(Typ.): 0.5 degrees with single fibre
Off-cut collector / Fibre offcut bin: Pre-fitted/TR-FC8R
Automatic blade rotation: Provided (Switchable to Fixed)
Cleave operation counter: Provided DC power supply : Coin type Lithium battery CR1220
Lid opening angle: Switchable (Wide/ Narrow)
Dimensions and Weight: 58(W)x98(D)x49(H)mm, Approx.260 g
Field replaceable blade: Yes, use FCP-20BL(7R)
Operating condition: -10-50°C and 0-95% RH(non-condensing)
Storage condition: -40-80°C and 0-95% RH(non-condensing)
Blade life: 60,000 fibres(2.500 fibres x24 positions)
Standard package: Main body, single fibre adapter, desktop spacer block, carrying case, operation manual, cleaning brush, hexagonal wrench, strap
