Temperature range: +40℃ to+80℃(*1)
Control accuracy: PID controller, ±0.5℃ (*2)
Heater output: 12.0kW
Pump capacity (50/60Hz):
Max. discharge pressure: 0.59MPa
Flow rate: 42/55 L/min (*3)
Motor output: 0.75kW
Water bath capacity (at 80% water level): 110L
Safety device/function: Short/Over current breaker, Phase-reversal relay, Warning and Cut off for low water, Circulating water high temperature, Pump overcurrent, Overheating protection
Connecting pipe diameter (Circulating fluid in/out): Rc1
Dimensions: 627×772×1130 mm
Weight: approx. 120kg
Power Supply (three phase AC200V, 50/60Hz): 50A
Operation current (50/60Hz): 38A
Catalog
(*1)The lower limit may change depending on operating conditions. Cannot be used for applications on circulating water returns for temperature increases.
(*2)Cooling water is required up to approx. +60℃.
(*3)Capacity when using tap water. The value when the discharge pressure at 0.3 MPa.
•The sensitivity current in ELCB should be set larger than 30 mA.
•The primary cooling water is required when the cooling function is added. The cooling capacity depends on the cooling water conditions (Water temperature and Flow rate).
