-Measurement method:
+Conductivity: AC 2-Electrode Method
+Temperature: Thermistor Resistor
-Conductivity Measuring frequency: 80Hz/3kHz Auto-selection
-Display unit: Customized LCD
-Measurement Item/Range:
+Conductivity: Depends on the cell
+Resistivity: Depends on the cell
+Salinity: Conversion from conductivity
+TDS: Conversion from conductivity
+Temperature: 0.0 ～100.0℃
-Display Range:
+Conductivity （Manual/Auto Range Switching） （Depending on the cell）:
0.0 ～ 200.0μS/m （0.000 ～ 2.000μS/cm）
0.000 ～ 2.000mS/m （0.00 ～ 20.00μS/cm）
0.00 ～ 20.00mS/m （0.0 ～ 200.0μS/cm）
0.0 ～ 200.0mS/m （0.000 ～ 2.000mS/cm）
0.000 ～ 2.000S/m （0.00 ～ 20.00mS/cm）
0.00 ～ 20.00S/m （0.0 ～ 200.0mS/cm）
0.0 ～ 200.0S/m （0.000 ～ 2.000S/cm）
SI unit （S/m） or （S/cm） selectable
+Resistivity （Manual/Auto Range Switching） （Depending on the cell）:
0.005 ～ 2.000 Ω･m （0.5 ～ 200.0Ω･cm）
0.00 ～ 20.00 Ω･m （0.000 ～ 2.000kΩ･cm）
00.0 ～ 200.0 Ω･m （0.00 ～ 20.00kΩ･cm）
0.000 ～ 2.000kΩ･m （0.0 ～ 200.0kΩ･cm）
0.00 ～ 20.00kΩ･m （0.000 ～ 2.000MΩ･cm）
00.0 ～ 200.0kΩ･m （0.00 ～ 20.00MΩ･cm）
0.000 ～ 2.000MΩ･m （0.0 ～ 200.0MΩ･cm）
0.00 ～ 20.00MΩ･m （0 ～ 2000MΩ･cm）
SI unit (Ω･m) and conventional unit (Ω･cm) selectable
+Salinity:
0.00 ～ 4.04% （NaCl）
0.00 ～ 42.40 (PSS:Sea water salinity)
+TDS （Manual/Auto Range Switching）:
0 ～ 99.99mg/L
0 ～ 999.9mg/L
0 ～ 9.999g/L
0 ～ 99.99g/L
0 ～ 999.9g/L
+Temperature: -5.0 ～110.0℃
- Repeatability（Meter main unit）:
+Conductivity: ±0.5% FS
+Resistivity: ±0.5% FS
+Salinity: ±0.5% FS
+TDS: ±0.5% FS
+Temperature: within ±0.2℃
-Temperature Compensation:
+Temperature Compensation Range:
ATC （Auto Temperature Compensation）：0 ～100.0℃
MTC（Manual Temperature Compensation）：0 ～100.0℃
+N/A: ATC OFF
+Standard Temperature Setting: 25℃ fixed
+Temperature Coefficient（Linear）: 0 ～10.00％／℃
-Temperature Calibration: 1-point Calibration
-Performance Guaranteed Temperature, Humidity: 0 ～ 45℃ 85％ or below（condensation-free）
-Data Memory: 1000 data
-Print Function: Connectable to optional external printer EPS-P30
-Auto Hold Fuction: yes
-Calibration History Creation Function: Latest one run
-Interval Measurement: yes
-External Input/Output:
+RS-232C Interface: yes （External Printer）
+USB (peripheral, Micro): yes
-Option Connection:
+External Printer: yes
-Power Source: AA Alkaline battery×4 or USB power feeding (No charging function).
-Power Consumption: Approx.1000 hours (estimated)
-Main Unit Dimensions （Excluding Protruding Parts）: Approx.130 W×60 H×230 Dmm
-Main Unit Weight: Approx. 0.7kg
-Inluding:
+ Main unit
+ Sensor Holder: 7430850K
+ Sensor stand (Stand, strut, stopper): 7430860K
+ Tilt stand: 7430870K
+ Sensor attachment (G): 0IB00004
+ Conductivity sensor: CT-58101B
+ Ground wire (2m): X0979500
+ Beakers (150mL): 0DE00001
+ AA Battery (4pcs)
+ Manual
-Tính năng:
+ Màn hình LCD lớn
+ DC (4 AA pin) / Nguồn cấp USB
+ Tuổi thọ pin lên đến 1000 giờ
+ Giao tiếp PC với kết nối USB
+ Bộ nhớ dữ liệu ( lên đến 1.000 dữ liệu)
+ Có thể kết nối với máy in bên ngoài (tùy chọn)
Dải đo:
0-200,0 S / m
0-20,00 MΩ · m
Chloride 0-4,00%
0-100 ° C
Ứng dụng: Thiết bị này dùng để đo pH, độ dẫn điện, điện trở, độ mặn, DO, TDS, nồng độ trong phòng thí nghiệm.
