Measuring Method: Coulometric titration method (end point is detected by potential difference).
Display: Graphic LCD panel (320 × 240 pixels) with back light. English/Japanese language is selectable.
Sample Injection Volume: 2, 20, 200 µL or OTHER (1 to 9999 µL)
Measuring Ranges (displayed by %):
2 µL dispenser: 0.00 to 49.99%, lower detection limit 2.0%
20 µL dispenser: 0.000 to 4.999%, lower detection limit 0.2%
200 µL dispenser: 0.0000 to 0.4999%, lower detection limit 0.02%
OTHER dispenser volume: 0.0000 to 99.99% (depends on calibration solution concentration)
Concentration Conversion: NaCl/Cl- switching
Concentration Units: % (W/V), % (W/W), mg/L, mol/L
Repeatability: 0.5% or less in C.V. value at 1% of NaCl standard solution with 20 µL micro dispenser
Calibration: Automatic single point calibration using NaCl standard solution with a concentration corresponding to the injection volume.
Measurement Start: Automatic start on detection of potential change or manual start by pressing START key.
Printer: Built-in thermal printer
Data Memory: 300 data points (with backup)
Output: RS-232C (can be connected to a PC or external printer)
Operating Temperature Range: 10 to 35°C (avoid sudden temperature changes)
Power Source: AC100 to 240V, 50/60Hz
Power Consumption: Approx. 20VA (maximum)
Dimensions, Weight:
Main Unit: Approx. 190(W) × 192(H) × 385(D) mm, Approx. 3.3 kg
Measurement Section: Approx. 110(W) × 370(H) × 220(D) mm, Approx. 1.1 kg
