Channel No.: 256
Workflow control method: Whole Cabin control
Charging model: Constant voltage,constant current
Charge cutoff condition: Voltage, current, time, capacity
Discharge mode: Constant current
Discharge cutoff condition: Voltage, time, capacity
Sampling inspection cycle: ≤10s
Voltagemeasurement range: 0~5V，Resolution 1mV
Battery voltage range: Charge：0~4.5V，Discharge：4.5~2V
Constant voltage range: 3~4.5V
Voltage accuracy: ±（0.05%RD+0.1%FS）
Current range: Charge:0.025-5A，Discharge :0.025-5A，Resolution:1mA
Current accuracy: ±（0.1%RD+0.1%FS）
Time Set Range: Any setting within 0~30000 minutes, the time unit is min
Time accuracy: ≤±0.1%
Clamp type: Four-wire method fixture
Clamp adjust range: 10mm-80mm
Support battery type: Square cell andCylinder cell
Voltage source: 3 phase 4 wire，AC380V±5%，50HZ，Power consumption 12KW
communication method: RS485，Baud rate 57600
Machine size: 1440mm（length）×500mm（width）×1840mm（height
working environment: Temperature：0-40℃，related temperature≤85%
Full load operating current: Phase line up to15A, zero line up to 3A
Device startup current: Air switch closing moment about 60A
N.W: About 350kg
